Pad Printing Ink/doctoring Cups

FOR CLEAN AND CONTROLLED PRINT IMAGE ACQUISITION

Ink/doctoring cups for any application

"ELECTROTECH" is well equipped with its facilities of making specialized ink cups of various companies. we can make ink cups in any material like metal, aluminium and special engineering plastics. we also rely on our process expertise when it comes to consumables! we have worked for decades on optimizing the closed system and can now offer the ink/doctoring cup that is ideally matched to the application. our range covers a range of different versions. whether with replaceable doctor rings, sophisticated ventilation concepts or for multicolor print images.

REASONS TO CHOOSE THE "ELECTROTECH" INK/DOCTORING CUPS

  • Available In Different Material Versions
  • Available In All Common System Sizes
  • Ink/doctoring Cups For Multicolored Print Images
  • Maintenance Package: Replacing And Machine Lapping Of The Doctoring Ring
Cup Body Material D (mm) Outer dia. d (mm) Inner dia. H (mm) Ring height Magnet
65 60 5.2 0
PL (Plastic cup) 96 90 5.2 0
135 130 5.2 0
Cup Body Material M (qty) Magnets D (mm) Outer dia. d (mm) Inner dia. H (mm) Ring height Ring Edge
6M 70 60 12 SS
8M 90 80 12 SS
8M 90 82 12 SS
AL (Aluminum Ink Cups) 8M 100 90 12 SS
12M 135 126 14 SS
12M 145 135 14 SS
16M 201 189 16 SS
