Three Color Pneumatic Pad Printing Machines

Model	Euro-85/250tcsu
No. of Colors	3
Doctoring Cup Dia [mm]	90
Print Speed [Max./Hrs]	540
Cliche/Plate Size [mm]	100 x 250
Print Image Size [⌀ mm]	85
Product Height [mm]	400
Power Consumption [W]	50
Control System	PLC with HMI
Control Voltage	12/24 VDC
Drive	Electro Pneumatic
Operating Pressure[Bar]	6-8
Air Consumption [Lit/min.]	100
Power Supply	230 VAC/50Hz.
Dimensions (Approx)[mm]	Length - 860
	Width - 680
	Height - 1465
Weight kgs (Approx)[Kgs]	192
